Optimized for High-Power LED Thermal Management Applications The 120W ZT Series LED Heat Sink targets engineers and system integrators seeking reliable thermal management for high-powered LED installations. Its role is to efficiently dissipate heat generated by LED components in demanding environments. Designed primarily for passive cooling, this solution supports enhanced LED lifespan and stable performance, addressing critical concerns in LED fixture design. The compact dimensions and moderate weight allow seamless integration into various luminaires, meeting diverse application needs across lighting engineering and manufacturing sectors.
Advanced Constructive Materials and Measurable Thermal Performance Utilizing a phase change heat transfer cooling principle, the 120W ZT Series LED Heat Sink efficiently reduces thermal resistance, measured at approximately 0.4150°C/W under 80W test conditions. The hybrid base plate construction, combining a copper core with aluminum layers, optimizes heat conduction and dissipation. Its Φ159 × 115 mm structure balances size and thermal efficiency, while weighing 1.30 kg for manageable installation. These specifications deliver quantifiable improvements in heat dissipation rates, sustaining LED module reliability within specified operational thermal loads.
Integration Versatility Across Multiple LED Industry Sectors This thermal component finds extensive use in LED street lighting, floodlights, architectural installations, and LED display modules. By providing passive cooling support, the 120W ZT Series LED Heat Sink facilitates compliance with stringent reliability and safety standards required in commercial and industrial LED applications. Its adaptability extends to OEM lamp manufacturing and prototype validations, enhancing the thermal design process. The product’s performance contributes to reducing maintenance cycles and overall lifecycle costs in system deployments involving energy-efficient LED lighting solutions.
Product Advantages
Structural and Design Optimization for Thermal Efficiency The 120W ZT Series LED Heat Sink features a carefully engineered base plate structure combining copper and aluminum segments, leveraging the advantages of both good thermal conductivity and lightweight design. The modular sizing (Φ159 × 115 mm) enables integration within a broad array of LED fixtures without compromising enclosure geometry. The implementation of a phase change heat transfer cooling mechanism enhances the system’s ability to manage variable thermal loads effectively. These design elements ensure that the heat sink serves as a reliable passive cooling solution compatible with diverse LED lighting architectures.
Enhanced Performance Delivering Operational Reliability Performance-wise, this heat sink’s low thermal resistance directly translates into improved LED efficacy and longevity. Its passive cooling design removes dependence on active components, reducing potential failure points and maintenance requirements. The 1.30 kg weight optimizes usability by facilitating easier handling during installation and replacement. This solution enhances overall system stability in high-power LED applications by maintaining junction temperatures within safe operating thresholds, which is critical for meeting performance and safety compliance benchmarks in engineering projects.
Use Scenarios
Thermal Management in LED Street and Flood Lighting In outdoor urban lighting environments, such as street and floodlighting, the 120W ZT Series LED Heat Sink plays a fundamental role in dissipating heat generated by high wattage LEDs. Its phase change heat transfer technology ensures efficient thermal pathways, which helps maintain system reliability over extended operational hours. The product’s compact form factor enables integration into constrained fixture designs common in these sectors. Employing this heat sink supports compliance with durability standards and reduces the risk of thermal degradation, thus facilitating long-term municipal and commercial lighting system operation.
Support for LED Display and Architectural Lighting Systems In commercial and architectural LED installations, this heat sink assists with maintaining optimal thermal conditions for LED arrays and modules. By effectively managing heat dissipation, the product ensures consistent lighting output and color stability important for high-quality displays and design-grade luminaires. The combined copper and aluminum construction provides necessary thermal conductivity while conforming to volumetric constraints typical in architectural systems. Integration of the 120W ZT Series LED Heat Sink into these applications enhances system performance, reduces downtime due to thermal stress, and supports rigorous quality standards in visual and functional lighting solutions.
FAQ
What materials are used in the 120W ZT Series LED Heat Sink construction? The 120W ZT Series LED Heat Sink features a combined base plate of copper (Ø30 mm × 3 mm) and aluminum (120 mm × 5 mm), optimizing heat conduction and dissipation for efficient thermal management in high-power LED fixtures.
Can the 120W ZT Series LED Heat Sink be customized for specific LED applications? Yes, Jiashan Haoye offers OEM and ODM services to tailor the 120W ZT Series LED Heat Sink for various LED applications, supporting design modifications to meet unique thermal management and size requirements.
How easy is it to install the 120W ZT Series LED Heat Sink in LED fixtures? With a compact size of Ф159 × 115 mm and moderate weight of 1.30 kg, the 120W ZT Series LED Heat Sink allows for straightforward integration into diverse LED lighting assemblies without adding excessive bulk or weight.
What packaging and shipping options are available for the 120W ZT Series LED Heat Sink? Jiashan Haoye ensures secure packaging and reliable logistics to maintain product integrity during transit. The 120W ZT Series LED Heat Sink is prepared for various export markets, meeting quality standards for industrial buyers worldwide.
